Hydraulic Fittings
SKU: MF-JIC-MC-001
Precision-machined JIC male connector for high-pressure hydraulic lines.
The Masofit JIC 37° Flare Male Connector delivers leak-proof hydraulic connections for industrial systems. Engineered for vibration resistance and long service life in demanding environments.
Click a number on the drawing to explore thread, body, seal, material, size, and standards for this product.
Key hydraulic fitting parameters used in this product and why they matter.
Material choice determines corrosion resistance, pressure capability, and service life in hydraulic systems.
Fitting size must match tube/hose OD and system flow demand. Undersizing causes pressure drop; oversizing adds cost and weight.
Imperial sizes (1/4", 3/8", 1/2") are common in hydraulic lines. Metric sizes (mm) are typical for pneumatic tubing. Always confirm thread and tube standards together.
Industry standards ensure interchangeability, sealing performance, and safety across hydraulic fittings.
Thread form controls how the fitting seals and mates with ports, adapters, and hose ends.
Connection geometry defines how fluid is routed — straight, angled, branched, or quick-connect.
| Material | Carbon Steel / Stainless Steel 316 |
|---|---|
| Pressure Rating | Up to 6,000 PSI |
| Temperature Range | -40°C to +120°C |
| Thread Type | UNF / JIC 37° Flare |
| Connection Type | Male Connector |
