Hydraulic Fittings
SKU: MF-HYD-TEE-001
Heavy-duty hydraulic tee for branch line connections.
Heavy-duty hydraulic tee fitting for branching high-pressure lines in industrial and mobile equipment.
Click a number on the drawing to explore thread, body, seal, material, size, and standards for this product.
Key hydraulic fitting parameters used in this product and why they matter.
Material choice determines corrosion resistance, pressure capability, and service life in hydraulic systems.
Fitting size must match tube/hose OD and system flow demand. Undersizing causes pressure drop; oversizing adds cost and weight.
Imperial sizes (1/4", 3/8", 1/2") are common in hydraulic lines. Metric sizes (mm) are typical for pneumatic tubing. Always confirm thread and tube standards together.
Industry standards ensure interchangeability, sealing performance, and safety across hydraulic fittings.
Thread form controls how the fitting seals and mates with ports, adapters, and hose ends.
Connection geometry defines how fluid is routed — straight, angled, branched, or quick-connect.
| Material | Stainless Steel 316 |
|---|---|
| Pressure Rating | Up to 6,000 PSI |
| Thread Type | NPT |
| Connection Type | Tee |
